Product Details
B.I.L. COIL
A printed circuit board coil on support handle with 5 and 10 turns rated at 2A. The lower arm of the coil is 75mm long (minimum) and 20mm wide.
Description
In use the coil is supported between the poles of 2 ferrite slab magnets on a yoke or in the adjustable magnet on the top pan of an electronic balance. When a current is passed through the coil the force can be easily measured by the change in reading on the balance and investigations into F=BIL can be carried out.
https://lascells.com/product/b-i-l-coil/
Looking for a simpler, more effective way to deliver the A-Level Physics required practical on the motor effect and the force on a wire in a magnetic field? In this video, we walk through a streamlined and classroom-friendly method to model the F = BIL relationship using a top pan balance. Ideal for physics teachers and lab technicians, this approach uses the Lascells BIL coil to amplify results and achieve rapid, fuss-free set up.
https://www.youtube.com/watch?v=zMZSt34W4c8
